WGT-1000 Wireless Online Single Glove Integrity Tester

Send Inquiry

Request To Call Back

WGT-1000 Wireless Online Single Glove Integrity Tester

Get a Price/Quote

WGT-1000 Wireless Online Single Glove Integrity Tester Specification

Specimen Size
Standard glove ports

Interface Type
Wireless, USB

Display Type
Digital LCD touchscreen

Hardness
N/A (not applicable)

Features
Wireless operation, automatic data logging, rapid leak detection, easy mounting and removal

Mounting Type
Clamp or flange mounting

Automation Grade
Fully automatic

Temperature
10C~40C

Resolution
0.01 ml/min

Gas Pressure
0.4~0.6 MPa

Accuracy
0.1 ml/min

Response Time
3 seconds

Test Range
0~1000 ml/min leakage

Power Supply
AC 220V, 50Hz

Measuring Range
0.1~1000 ml/min

Application
Glove leak/air tightness testing in isolators, RABS, and gloveboxes

Number of Specimens
1 glove

Frequency
50 Hz

Humidity
10%~90% RH

Port Size
Standard (customizable available)

Equipment Type
Online Glove Integrity Tester

Operating Voltage
220VAC

Max Height
400 mm (including mounting)

Usage
Online glove integrity/leak testing

Capacity
Single glove station

Machine Weight
15 kg

Test Speed
Adjustable (per user requirement)

Test Width
250 mm

Test Stroke
Standard 350 mm

Control Mode
Wireless remote control

Battery Backup
Up to 2 hours operation (optional)

Calibration
Factory calibrated, user calibration optional

Memory Storage
Internal log up to 500 test records

Data Output
Exportable via USB or wireless connection

Compliance
Meets ISO 14644-7 and GMP guidelines

Alarm System
Visual and audible alarm for failed tests

Material of Construction
Stainless steel body with polycarbonate housing

Language Support
Multi-language (English/Chinese/German)

Protection Class
IP54

Communication Protocol
Wi-Fi 802.11b/g/n

About WGT-1000 Wireless Online Single Glove Integrity Tester

Instrument characteristics:

It is connected to the PC wirelessly via WIFI, and the detection data can be transmitted wirelessly.
Supporting powerful upper computer management software, which can manage multiple detection units at the same time.
RFID chip technology, automatic identification of glove number, included in the test result.
Meet the IP65 protection level, which is convenient for disinfection and cleaning of equipment.
There are multiple program settings to meet the testing requirements of gloves of different specifications and materials.
The pressure detection range can reach 3000Pa, covering all glove detection pressures.
Automatically monitor the pressure in the inflatable sealing ring and the glove during the test.
The instrument uses a small amount of frequent air intake, and the air intake speed in the glove is uniform to avoid deformation of the glove.
Color touch screen, user-friendly interface design, and can automatically select and match the testing program that best suits the current glove according to different test parameters, and display the date and time.
Easy to move, easy to carry, fast connection.
Historical records can be transmitted, stored, and inquired.
According to customer needs, we can customize pallets of different sizes to achieve multiple pallet operations on one machine.
Comply with FDA/GMP and other regulations and computer system verification requirements.
The software complies with 21CFR part11 electronic records and electronic signature certification requirements.

Application field:

Pharmaceutical industry: sterile inspection and microbial limit inspection of purified water, water for injection, sterile preparations (large infusion, small injection, powder, biological products, blood products, ophthalmic preparations, maintenance solutions, etc.).
Medical equipment industry: sterility inspection and microbial limit inspection of purified water, water for injection, syringes, infusion sets, blood transfusion sets, intravenous catheters, etc.
Food and beverage industry.
Environmental protection industry, etc.

Reliable Online Glove Leak Testing

Detect glove integrity issues quickly with the WGT-1000 tester, designed for single-glove stations in isolators and RABS. Its rapid, wireless-controlled operation and easy mounting options cater to high-demand environments, providing efficient protection for product and personnel safety.

Compliant and Versatile Design

Fully meeting ISO 14644-7 and GMP guidelines, the WGT-1000 delivers reliable test results across various industries. The robust stainless steel body with IP54 protection, a digital LCD touchscreen, and the flexibility to export data wirelessly or via USB make it suitable for both manufacturers and quality assurance labs.

FAQ's of WGT-1000 Wireless Online Single Glove Integrity Tester:

Q: How does the WGT-1000 Glove Integrity Tester operate?

A: The WGT-1000 uses a fully automatic process to test a single glove's airtightness by applying controlled gas pressure and monitoring for leakage. It is operated wirelessly via remote control and provides both visual and audible alarms for failed tests.

Q: What are the main benefits of using the WGT-1000 for glove leak testing?

A: Users benefit from rapid test speeds (response time 3 seconds), high accuracy (0.1 ml/min), and automatic data logging. Its compliance with ISO and GMP standards ensures reliable, traceable results for quality assurance.

Q: When should the Glove Integrity Tester be calibrated?

A: The device comes factory calibrated, but users can perform optional calibrations as needed based on company protocols or compliance requirements.

Q: Where can test data be accessed and exported from the device?

A: Test records, stored in the internal memory (up to 500 entries), can be exported via USB or wirelessly. The digital LCD touchscreen also allows for convenient on-site review.

Q: What is the typical process for mounting and using the WGT-1000?

A: Mount the device using clamp or flange options on the glove port, initiate the test wirelessly, and follow the on-screen prompts. The tester automatically logs results and issues alarms if leaks are detected.

Q: Can the tester accommodate different glove port sizes or types?

A: The WGT-1000 supports standard glove ports and also offers customizable port sizes to fit unique equipment needs, enhancing compatibility across applications.

Q: What environments is the WGT-1000 suitable for?

A: With IP54 protection, stainless steel construction, and an operating range of 10C-40C with up to 90% humidity, the WGT-1000 works well in diverse, critical cleanroom and manufacturing settings.
