UV-VIS 1000 Spectrophotomet

Get a Price/Quote

UV-VIS 1000 Spectrophotomet Specification

Measurement Range
190 nm - 1100 nm

Voltage
220 V

Accuracy
0.2 nm

Frequency
50 Hz

Feature
Wide wavelength range, High accuracy measurement

Power Source
AC Electric

Temperature Range
5C to 40C

Automation Grade
Automatic

Capacity
Double Beam / Single Beam selection

Model No
UV-VIS 1000

Core Components
Deuterium Lamp, Tungsten Lamp, Photodiode Detector

Equipment Materials
Corrosion Resistant Material, ABS Plastic

Type
UV-VIS Spectrophotometer

Usage
Laboratory and Research Applications

Display Type
7 Inch TFT LCD touch screen display

Dimension (L*W*H)
540 mm x 450 mm x 260 mm

Weight
15 kg

Lamp Type
Pre-aligned deuterium and tungsten lamps

Light Source Life
2000 hours

Photometric Range
-0.3 to 3.0 Abs

Sample Holder
Standard cuvette (10 mm) holder

USB Interface
Available for data transfer

Baseline Flatness
0.001 Abs

Spectral Bandwidth
2 nm

Software
Integrated with quantitative & qualitative analysis

Scan Speed
Fast, Medium, Slow

Operating Humidity
<80% RH (non-condensing)

Data Storage
Internal and external via USB

About UV-VIS 1000 Spectrophotomet

Standard Features of Double Beam Spectrophotometer - UV 1000

Dual monochromator technology, making it well suited to even the most demanding applications in all areas.
Wireless instrument control and data acquisition can be achieved from a Tablet PC using Wi-Fi technology.
Measurements at deep ultra-violet wavelengths can also be achieved with the use of nitrogen-purged optics.
Thermostatic cell holders for temperature control.
Emissions lamp used for automatic correction of spectral deviation

Advanced Optical Performance

Experience high-quality results with a spectral bandwidth of 2 nm and an exceptionally flat baseline (0.001 Abs). The UV-VIS 1000 uses pre-aligned deuterium and tungsten lamps for reliable illumination, ensuring accurate and consistent measurements across a broad wavelength range (190 - 1100 nm).

User-Friendly Design & Operation

Operating the spectrophotometer is straightforward thanks to its 7-inch TFT LCD touchscreen. The instrument's intuitive interface and automatic mode facilitate efficient data acquisition, analysis, and storage. Its robust ABS plastic and corrosion-resistant build provide durability in demanding research or laboratory settings.

Versatile Connectivity & Data Management

Seamlessly store and transfer data internally or externally via USB, supporting flexible integration into various laboratory setups. The UV-VIS 1000's integrated analysis software streamlines quantitative and qualitative measurements, optimizing workflow efficiency for research and industrial applications.

FAQ's of UV-VIS 1000 Spectrophotomet:

Q: How do I transfer data from the UV-VIS 1000 Spectrophotometer to a computer?

A: You can transfer data using the available USB interface. Simply connect a USB drive or link the instrument directly to your computer to export both raw and processed measurement data.

Q: What types of laboratory applications is the UV-VIS 1000 suitable for?

A: This spectrophotometer supports a variety of quantitative and qualitative analyses, making it ideal for general research, chemical, biochemical, pharmaceutical, and environmental laboratory applications.

Q: When should I replace the light sources in the instrument?

A: The pre-aligned deuterium and tungsten lamps have an expected operating life of at least 2000 hours. It's best to monitor lamp usage and replace them when nearing the end of this timeframe or if measurement quality declines.

Q: Where can I install the UV-VIS 1000 Spectrophotometer?

A: Install the spectrophotometer in laboratories and research environments where the ambient temperature is between 5C and 40C, and relative humidity remains below 80% (non-condensing). Its corrosion-resistant build allows use in varied conditions.

Q: What is the process for performing a measurement?

A: To measure a sample, place it in the standard 10 mm cuvette holder, select the desired scan speed (fast, medium, or slow), and use the on-screen controls to initiate auto or manual measurement. Results are displayed on the LCD and can be saved or exported instantly.

Q: How does the double beam/single beam selection benefit users?

A: The capacity to choose between double and single beam modes allows for flexible operation; double beam mode compensates for variations in lamp intensity and sample turbidity, improving measurement accuracy for critical analyses.
