VDM 1000 Vibratory Disc Mill

Get a Price/Quote

VDM 1000 Vibratory Disc Mill Specification

Voltage
220/240 V Volt (v)

Temperature Range
Ambient to 40 C Celsius (oC)

Accuracy
High grinding reproducibility %

Core Components
Grinding Disc, Motor, Clamping System

Power Source
Electric

Measurement Range
Depends on initial sample size

Feature
Rapid grinding; sealed grinding containers; dust-free operation

Model No
VDM-1000

Frequency
50/60 Hz Hertz (HZ)

Automation Grade
Semi-Automatic

Capacity
1000 ml Milliliter (ML)

Equipment Materials
Stainless Steel Housing & Chamber

Type
Vibratory Disc Mill

Usage
Grinding and pulverizing hard, brittle materials

Display Type
Analog

Dimension (L*W*H)
615 x 525 x 510 mm Millimeter (mm)

Weight
Approx. 210 kg Kilograms (kg)

Grinding Time
30 seconds to 3 minutes (adjustable)

Maximum Feed Size
Up to 15 mm

Chamber Capacity
1000 ml

Clamping System
Manual clamping with safety lock

Safety Features
Safety interlock, overload protection

Disc Material Options
Manganese Steel, Tungsten Carbide, Zirconium Oxide

Final Fineness
Typically < 100 m

Motor Power
1.1 kW

Noise Level
<75 dB(A)

About VDM 1000 Vibratory Disc Mill

Standard Features of Vibratory Disc Mill VDM 1000 Series

Uniform sampling granularity, fast, reliable, high grinding efficiency.
Grinding material can be used directly without screening, fewer process, high production efficiency
Reasonable design: the whole sealed design, no dust pollution, conforms to environmental compliance.
Stable operation. low noise, reaches the safety requirements
Compact structure, easy maintenance, and handle
One to three samples can be ground at the same time
Grinding pot is made of especial anti-wear material and sealed well without any loss samples
Timer is optional for equipment.

Applications

Ceramics and glass : oxide Ceramics ,glass
Building Materials : Cement, stone, Concrete ,clinker ,Raw meal etc.
Environmental area : Soil , paving stone , slag
Minerals & Metallurgy : Coal ,coke ,corundum ,ore ,slag

High-Efficiency Grinding Performance

Designed to handle tough, hard, and brittle samples, the VDM 1000 provides rapid, uniform, and reproducible grinding results. Achieving fineness levels typically below 100 m, this mill is ideal for sample preparation in material science, mining, and analytical laboratories. Users can adjust the grinding time from 30 seconds up to 3 minutes to suit specific requirements and sample types.

Robust Construction with Superior Safety Features

Engineered with a durable stainless steel housing and chamber, the VDM 1000 ensures long-term reliability and easy cleaning. Key safety features include a safety lock, interlock mechanisms, and overload protection, minimizing operational risks. The dust-tight, sealed container design promotes safe handling while maintaining a noise level under 75 dB, making it suitable for laboratory environments.

Versatile Application and User-Friendly Operation

Accepting feed materials up to 15 mm, the VDM 1000 offers flexibility with a choice of grinding disc materials such as manganese steel, tungsten carbide, or zirconium oxide. The analog display, semi-automatic operation, and manual fastening system guarantee straightforward usage and accurate results. Its compact footprint allows for convenient placement in most lab settings in India and beyond.

FAQ's of VDM 1000 Vibratory Disc Mill:

Q: How does the VDM 1000 Vibratory Disc Mill achieve dust-free grinding?

A: The VDM 1000 is engineered with sealed grinding containers and a robust stainless steel housing. This design prevents dust release during the pulverization of hard or brittle samples, ensuring a clean laboratory environment and safer operation.

Q: What materials can be processed with the VDM 1000 and which disc types are available?

A: The mill is suitable for grinding and pulverizing hard, brittle materials up to 15 mm in feed size. Users can choose from manganese steel, tungsten carbide, or zirconium oxide grinding discs, depending on sample composition and analytical requirements.

Q: When should grinding time be adjusted between 30 seconds and 3 minutes?

A: The grinding time depends on the initial sample size, material hardness, and the desired final fineness. Adjust shorter times for moderately hard materials and longer durations for tougher or denser samples to achieve fine, reproducible results below 100 m.

Q: Where can the VDM 1000 be installed and what are the space requirements?

A: Its compact dimensions (615 x 525 x 510 mm) make the VDM 1000 suitable for various laboratory environments in India. It can be easily placed on a sturdy laboratory bench or table, provided adequate ventilation and access to a 220/240V electric supply.

Q: What process ensures operator safety during grinding?

A: Operator safety is maintained through a manual clamping system with a safety lock, a safety interlock that prevents operation when open, and overload protection to automatically stop the motor if overloaded.

Q: How is the result accuracy maintained during the grinding process?

A: The VDM 1000 ensures high reproducibility by providing adjustable grinding times, sealed grinding conditions, and a steady motor operation, minimizing sample contamination and particle size variability.

Q: What are the main benefits of using the VDM 1000 for laboratory grinding applications?

A: Users benefit from rapid, controlled, and dust-free grinding with reliable safety features, low noise, and flexible operation. Its design ensures consistent sample preparation for precise analytical results, enhancing productivity and laboratory workflow.
