854301-1 Dust Trak Environmental Monitor

Get a Price/Quote

854301-1 Dust Trak Environmental Monitor Specification

Application Media
Air and Aerosol Monitoring

Temperature Range
-20C to +50C (Operation)

Measurement Range
0.001 to 400 mg/m (fraction dependent)

Connectivity Type
Ethernet, USB, RS232, Cellular (Optional), Wi-Fi (Optional)

Diameter
PM1, PM2.5, PM4, PM10 size fractions

Capacity
Internal Data Logging (up to 5 million data points)

Sensor Type
Laser Photometer

Flow Rate
1.7 L/min (factory calibrated)

Resolution
0.001 mg/m

Equipment Type
Dust and Aerosol Environmental Monitor

Humidity %
0 to 95% RH, Non-condensing

Protection
IP65 Rated Enclosure

Frequency
50/60 Hz

Material
Polycarbonate Enclosure

Power Supply
100 240 VAC, 50/60 Hz, 24 VDC adapter

Power Consumption
Maximum 60 W

Accuracy
0.1 mg/m for <1.0 mg/m; 10% of reading for >1.0 mg/m

Display Type
7-inch color touch screen

Range
0.001 to 400 mg/m

Inlet Design
Heated Inlet Module for humidity compensation (optional)

Dimensions (L x W x H)
27.4 x 22.9 x 55.9 cm (10.8 x 9 x 22 in)

Alarm Output
1 relay, 2A @ 240 VAC max, 4 - 20 mA output

Operating Altitude
Up to 3,048 m (10,000 ft)

Power Backup
Optional external battery pack

Software Compatibility
Environmental Data Management Software Suite

Calibration
Factory calibrated, on-site zero/span calibration possible

Data Storage
Internal SD Card, USB data transfer

Compliance Standards
CE, RoHS, EN 61326-1

Weight
13.6 kg (30 lb)

About 854301-1 Dust Trak Environmental Monitor

Applications

Outdoor environmental monitoring
Monitoring for a Community Air Monitoring Plan (CAMP)
Fugitive emissions monitoring
Site perimeter monitoring
Brownfields/remediation monitoring
Fence-line monitoring
Dust control operations
Environmental research studies
Construction site monitoring
Harsh industrial environmental monitoring
Urban pollution studies

Features & Benefits

Simultaneously measure size-segregated mass fraction concentrations corresponding to PM1, PM2.5, respirable, PM10, and total PM size fractions
Minimal set-up
New tri-pod mount capability
Easy-to-use custom alarm settings for alerts anytime, anywhere
Perform in-line gravimetric analysis for custom reference calibrations
Aerosol concentration range 0.001 to 150 mg/m³
Environmentally protected and tamperproof with environmental enclosure
MCERTS certified models now available for PM2.5, PM10, and total PM, respectively
On the South Coast AQMD pre-approved list of instruments for Rule 1466
Automatic differential calculations between upwind and downwind values

Advanced Monitoring Performance

With a measurement range from 0.001 to 400 mg/m3 and resolution down to 0.001 mg/m3, the 854301-1 Dust Trak ensures comprehensive detection of airborne particulates. Its factory-calibrated laser photometer delivers high accuracy (0.1 mg/m3 for low concentrations, 10% for higher readings), making it ideal for various air quality applications.

Robust and Convenient Design

The IP65-rated polycarbonate enclosure makes the monitor suitable for outdoor and industrial settings, while the 7-inch color touch screen allows intuitive operation. Optional features like a heated inlet module and external battery backup enhance adaptability across different environments and monitoring requirements.

Enhanced Data Management

The internal SD card can store up to 5 million data points, with USB data transfer supporting seamless access and archiving. Integration with Environmental Data Management Software Suite allows for advanced analysis, ensuring users can review and interpret air quality data efficiently.

FAQ's of 854301-1 Dust Trak Environmental Monitor:

Q: How is data retrieved from the 854301-1 Dust Trak Environmental Monitor?

A: Data is stored on an internal SD card and can be transferred via USB. Additionally, connectivity via Ethernet, RS232, and optional Wi-Fi or Cellular modules enable flexible integration with data management systems.

Q: What calibration options are available for this monitor?

A: The device comes factory calibrated and supports on-site zero/span calibration, providing reliable accuracy and allowing users to adjust the unit for their specific monitoring conditions.

Q: When is the optional heated inlet module recommended for use?

A: The heated inlet module is advised in high-humidity environments. It actively compensates for moisture, preventing condensation interference and ensuring accurate particulate measurements.

Q: Where can the Dust Trak Environmental Monitor be used?

A: Its IP65-rated enclosure and operational temperature range of -20C to +50C make the monitor suitable for both indoor and outdoor applications, such as industrial sites, environmental monitoring stations, and construction zones.

Q: What process is followed to ensure compliance with regulatory standards?

A: The 854301-1 complies with CE, RoHS, and EN 61326-1 standards. Each unit is tested during manufacturing to meet these requirements, helping users achieve regulatory satisfaction in their environmental monitoring.

Q: How does the alarm output function benefit users?

A: The relay alarm output (1 relay, 2A @ 240 VAC max) can activate external warning systems or process controls when particulate concentrations exceed user-set thresholds, enabling responsive action to hazardous air quality events.

Q: Can the device operate during power outages?

A: Yes, with an optional external battery pack, the Dust Trak Environmental Monitor continues functioning during power interruptions, maintaining continuous air quality monitoring.
