Polludrone Multiparameter Air Quality Monitoring System

Get a Price/Quote

Polludrone Multiparameter Air Quality Monitoring System Specification

Measurement Range
Customizable for various gases (NO2, SO2, CO, O3, etc.)

Frequency
50/60 Hz

Application Media
Ambient Air Monitoring

Flow Rate
> 2 L/min (typical sample flow)

Protection
IP65 Weatherproof Enclosure

Equipment Type
Multiparameter Air Quality Monitoring System

Diameter
190 mm

Temperature Range
-20C to +60C

Wind Speed
060 m/s

Capacity
Continuous monitoring, supports data logging

Sensor Type
Optical Particle Counter, Electrochemical, NDIR, Semiconductor sensors

Humidity %
0%95% RH, non-condensing

Resolution
0.1 g/m for PM, as per gas sensor spec

Pressure Range
3001100 hPa

Connectivity Type
GSM, Ethernet, Wi-Fi, Modbus, RS-485

Current Range
420 mA (sensor output integration)

Material
UV Stabilized Polycarbonate, Aluminum

Power Supply
100240 V AC, 50/60 Hz

Power Consumption
< 30 W

Accuracy
Up to 2% (varies by parameter)

Display Type
Digital LED Display

Range
PM10: 01000 g/m; PM2.5: 0500 g/m; Gaseous pollutants: see datasheet

Mounting Type
Pole/Wall Mountable

Alarm Function
Configurable threshold alerts

Firmware Update
OTA (Over-the-air)

Device Interface
Web-based Dashboard & Mobile App

Response Time
< 60 seconds

Data Output
Real-Time, API Integration

Weight
~3.2 kg

Communication Protocol
TCP/IP, MQTT, HTTP

Power Backup
Optional Battery Backup

Access Control
Password Protected Interface

Data Storage
Cloud & SD Card Supported

Dimensions
210 mm (H) x 190 mm (Dia) x 165 mm (D)

Enclosure Color
White/Black

Operating Altitude
Up to 2000 m

About Polludrone Multiparameter Air Quality Monitoring System

Product Features:

Patented Technology : Works on innovative e-breathing technology for higher data accuracy.
Retrofit Design: Plug-and-play design for ease of implementation.
Compact: Lightweight and compact system that can be easily installed on poles or walls.
Internal Storage: Internal data storage capacity of up to 8 GB or 90 days of data.
On-device Calibration: On-site device calibration capability using built-in calibration software.
Identity and Configuration: Geo-tagging for accurate location (latitude and longitude) of the device.
Tamper-Proof: IP 66 grade certified secure system to avoid tampering, malfunction, or sabotage.
Over-the-Air Update: Automatically upgradeable from a central server without the need for an onsite visit.
Network Agnostic: Supports a wide range of connectivity options, including GSM, GPRS, Wi-Fi, LoRa, NBIoT, Ethernet, Modbus, Relay, and Satellite.
Real-Time Data: Continuous monitoring with real-time data transfer at configurable intervals.
Weather Resistant: Durable IP 66 enclosure designed to withstand extreme weather conditions.
Fully Solar Powered: 100% solar-powered system, ideal for off-grid locations.

Key Benefits:

Robust and Rugged: Designed with a durable enclosure to withstand extreme climatic conditions.
Secure Cloud Platform: A secure platform for visualizing and analyzing data, with easy API integration for immediate action.
Accurate Data: Provides real-time, accurate readings to detect concentrations in ambient air.
Easy to Install: Effortless installation with versatile mounting options

Comprehensive Air Quality Data

Polludrone provides continuous, real-time measurement of particulate matter and various gaseous pollutants, including customizable monitoring for NO2, SO2, CO, and O3. The integrated optical and electrochemical sensors deliver high-resolution data, supporting rapid detection and in-depth analysis of air quality trends. Suitable for diverse applications, it is a valuable tool for environmental research, regulatory compliance, and industrial monitoring.

Versatile Connectivity and Data Integration

Equipped with GSM, Ethernet, Wi-Fi, Modbus, RS-485, and support for TCP/IP, MQTT, and HTTP protocols, Polludrone seamlessly integrates with existing systems. Real-time data can be accessed via a web dashboard or mobile app, with secure, password-protected interfaces. API integration allows effortless data sharing, while cloud and SD card storage ensure reliable data logging under any scenario.

Durable and Weatherproof Design

Built for outdoor installation, Polludrone features an IP65-rated, UV-stabilized polycarbonate and aluminum enclosure. The unit operates reliably in temperatures from -20C to +60C and up to 95% relative humidity, safeguarding the hardware from harsh weather. Its robust construction and optional battery backup guarantee uninterrupted monitoring up to altitudes of 2000 meters.

FAQ's of Polludrone Multiparameter Air Quality Monitoring System:

Q: How do I install the Polludrone Multiparameter Air Quality Monitoring System?

A: Installation is straightforward-Polludrone can be mounted on either a pole or a wall using the provided brackets and hardware. Once mounted, simply connect it to a power source (100-240 V AC), and configure network connectivity (GSM, Ethernet, Wi-Fi, or RS-485) as required for your site.

Q: What pollutants and parameters can Polludrone monitor?

A: Polludrone is capable of measuring particulate matter (PM2.5, PM10), temperature, humidity, wind speed, pressure, and customizable gaseous pollutants such as NO2, SO2, CO, and O3. Specific measurement ranges and resolutions are tailored according to the selected sensor configurations.

Q: When will I receive notifications for air quality threshold breaches?

A: Polludrone features configurable alarm functions. You can set personalized threshold values for each parameter through the web dashboard or app. The system will provide real-time alerts instantly when thresholds are exceeded, enabling timely action.

Q: Where can I access and analyze the air quality data collected?

A: All recorded data is accessible both remotely and locally. Real-time and historical datasets are viewable through the secure web-based dashboard and mobile app. For data backup or offline analysis, data can also be exported from the cloud or SD card.

Q: What is the process for updating the system's firmware?

A: Firmware updates are conveniently managed via over-the-air (OTA) processes. When new versions are released, you can initiate updates remotely through the device's web dashboard, ensuring the system always operates with the latest enhancements.

Q: How does Polludrone benefit my air quality monitoring initiatives?

A: Polludrone offers rapid, high-accuracy, multiparameter monitoring with robust data logging and integration options. Its real-time alerts, durable construction, and flexible connectivity enable proactive management, compliance verification, and actionable insights for urban, industrial, or research environments.

Q: Is technical support available for device setup and maintenance?

A: Yes, as a distributor, manufacturer, and service provider in India, technical support is readily available for setup, calibration, maintenance, and integration. Assistance can be requested through official channels for smooth deployment and reliable operations.
