Testo 176 P1 - Data Logger For Absolute Pressure Temperature And Humidity

Get a Price/Quote

Testo 176 P1 - Data Logger For Absolute Pressure Temperature And Humidity Specification

Temperature Range
-20 to +70C

Power Supply
3 x AA batteries or via mains unit (optional)

Theory
Electronic measurement and data logging

Data Capacity
Up to 2 million data readings

Alarm
Optical alarm (LED) for individually adjustable limit values

Type
Data Logger for Absolute Pressure, Temperature, and Humidity

Display Type
Large, clear LCD

Memory
2 million measurement values

Accuracy
Pressure: 3 mbar (at +25 C, 1013 mbar); Temperature: 0.2C (-20 to +70C); Humidity: 2 %RH (2 to 98 %RH at +25 C)

Size
103 x 63 x 33 mm

Resolution
Pressure: 0.1 mbar; Temperature: 0.1C; Humidity: 0.1 %RH

Battery
3 x AA batteries

Net Weight
Approx. 220 g

Standby Time
Up to 8 years (typical with standard measurements)

Interface
USB, SD card

Measuring Range
Pressure: 600 to 1100 mbar; Temperature: -20 to +70C; Humidity: 0 to 100%RH

Includes
Testo 176 P1 logger, wall holder, lock, batteries, calibration protocol

Sampling Rate
Adjustable from 1 sec to 24 hours

Calibration Interval
12 months recommended

Compliance
EN 12830, CE-certified

Protection Class
IP65

Software Compatibility
Testo ComSoft Basic/Professional

Sensor Type
Internal sensor for pressure, external probe for temperature/humidity (optional)

Data Export
CSV via USB or SD card

Mounting
Wall mount and optional magnetic mount

Operating Temperature
-20 to +70°C

About Testo 176 P1 - Data Logger For Absolute Pressure Temperature And Humidity

Advantages

Continuous measurement and documentation of absolute pressure
Two optionally connectable probes for humidity and temperature values
Large measurement data memory for up to 2 million measurement values
Software for data evaluation on a PC

Versatile Multi-Parameter Measurement

Monitor absolute pressure, temperature, and humidity simultaneously using Testo 176 P1. Its internal pressure sensor and optional external probe allow for comprehensive environmental data logging, making it suitable for sectors like pharmaceuticals, food storage, and industrial monitoring.

Reliable Operation and Easy Installation

With IP65 ingress protection, the Testo 176 P1 withstands harsh conditions, ensuring reliable use whether wall-mounted or magnetically attached. The device's long battery life (up to 8 years) and clear LCD display support uninterrupted routine monitoring.

Robust Data Storage and Management

Store up to 2 million data readings with adjustable sampling rates from 1 second to 24 hours. Export data seamlessly via USB or SD card and manage it with Testo ComSoft software for in-depth analysis and reporting to meet audit and compliance requirements.

FAQ's of Testo 176 P1 - Data Logger For Absolute Pressure Temperature And Humidity:

Q: How do I install and set up the Testo 176 P1 data logger?

A: The Testo 176 P1 can be easily installed on a wall using the included holder or attached magnetically with the optional magnetic mount. Simply insert the three AA batteries, use the clear LCD to navigate setup, configure limits and sampling intervals with Testo ComSoft Basic/Professional software, then begin logging.

Q: What process should I follow to export data from the logger?

A: Data can be exported by connecting the logger to a computer via USB or inserting an SD card. Download the stored measurements as CSV files and analyze or archive them using Testo ComSoft software for convenient reporting.

Q: When should the Testo 176 P1 be calibrated, and how often is this necessary?

A: It is recommended to calibrate the Testo 176 P1 every 12 months to maintain measurement accuracy. A calibration protocol is included, and periodic recalibration ensures compliance with EN 12830 and consistent data quality.

Q: Where can the Testo 176 P1 be used most effectively?

A: This data logger excels in environments where monitoring of pressure, temperature, and humidity is critical, such as laboratories, manufacturing facilities, pharmaceutical storage, and clean rooms, thanks to its rugged build and IP65 protection.

Q: What is the benefit of the optical alarm feature on the logger?

A: The optical (LED) alarm notifies users instantly when user-defined measurement limits are breached, enabling prompt corrective action and ensuring critical conditions do not go unnoticed.

Q: How accurate are the measurements provided by the Testo 176 P1?

A: This logger offers high accuracy: 3 mbar for pressure (at +25C, 1013 mbar), 0.2C for temperature (across -20 to +70C), and 2 %RH for humidity (2 to 98 %RH at +25C), supporting precise environmental monitoring.
