BCI-3000 Bomb Calorimeter

Get a Price/Quote

BCI-3000 Bomb Calorimeter Specification

Temperature
Operating: 10C to 40C

Port Size
Standard filling port

Frequency
50 Hz

Equipment Type
Bomb Calorimeter

Mounting Type
Bench-top

Test Range
Up to 10000 calories/g

Accuracy
0.2%

Interface Type
RS232 serial port

Automation Grade
Automatic

Operating Voltage
230V

Hardness
Corrosion-resistant bomb material

Display Type
Digital LCD display

Specimen Size
1 g to 2 g

Number of Specimens
Single specimen per test

Max Height
350 mm

Gas Pressure
Max Oxygen Pressure: 30 atm

Power Supply
230V AC, 50Hz

Resolution
0.01 cal

Measuring Range
Up to 10000 cal/g

Humidity
Operating: 80% RH Max

Application
Calorific value measurement of solid and liquid fuels

Features
Fully automatic, robust construction, user-friendly interface

Response Time
Less than 1 minute

Usage
Laboratory/Industrial

Capacity
Up to 350 ml water jacket

Machine Weight
Approximately 25 kg

Test Speed
Automatic measurement

Test Width
Standard Bomb Diameter: 65 mm

Test Stroke
Standard test stroke

Control Mode
Microprocessor-based control

Ignition System
Automated electric ignition

Water Measurement Accuracy
±1 ml

Calibration Method
Electronic automatic calibration

Software Support
PC compatible data logging software

Data Storage
Internal memory for up to 100 test records

Service Support
On-site installation and training available

Bomb Type
Removable combustion bomb

Body Material
Stainless steel chamber

Cooling Type
External cooling coil

Operator Training
Comprehensive user manual included

Test Environment
Anti-vibration platform

Safety Features
Pressure relief valve, overheat protection

About BCI-3000 Bomb Calorimeter

Standard Features of Tablet Friability Tester

The Combustion Bomb is thick walled, halogen, corrosion and acids resistant.
The instrument can be configured with either built in LCD Display(Touch Screen Optional), Computer or both.
This provides the user with the display of their choice of other displays and interfacing ports are also available.
All the processes in the experiment after putting the Charged Bomb on the hook are Automatic. There is no need to manually Measure Water, Adjust Water Temperature etc. thereby reducing operator workload and the errors associated with the same.
Correction for Acid, or Nitrogen, Fuse-wire, Sulphur, Moisture, Spiking, Ash and Hydrogen etc are available in the software.
Software customization allows user selectable analysis mode of : Isothermal, High Precision Mode Predictive Mode, Regnault-Pfaundler and several other modes.
A high accuracy automatic water Measuring and Dosing System is used to measure the quantity of water in the Calorimeter Vessel, ensuring the water dosing is accurate and reliable.
A high-efficiency stirrer ensures that the water in the inner calorimeter vessel is maintained uniformly throughout the experiment.
Specially designed Auto-stop and Auto-drain valves ensure leakage proof Jacketed System.
Window based easy to use software which can further be linked to Digital Weighing Scale for auto weight transfer.
A powerful but easy to use software is used for controlling the operation of the instrument. Apart from providing the user with complete control over the various modes and operation of the instrument, a customized reporting as per customer requirement is possible

Precision and Automation Combined

Experience automatic testing with the BCI-3000 Bomb Calorimeter, featuring microprocessor-based control, automated electric ignition, and electronic calibration. Designed for rapid and reliable measurement of calorific values, it ensures consistent accuracy and repeatable results in less than a minute. The robust stainless steel body and corrosion-resistant materials offer long-lasting performance in demanding laboratory or industrial environments.

Safety at the Forefront

The BCI-3000 prioritizes user safety with integrated overheat protection and a pressure relief valve. Its anti-vibration platform and external cooling coil further enhance stable and secure operation during high-precision measurements. With comprehensive safety features, you can confidently handle energetic reactions without concern for equipment or operator risk.

Effortless Data Management

Record, store, and analyze your test data efficiently with PC-compatible data logging software and onboard memory for up to 100 records. The RS232 interface allows seamless communication with your computer, and the intuitive digital LCD display ensures all key information is easy to read. The system's fully automatic process reduces operator handling and boosts laboratory productivity.

FAQ's of BCI-3000 Bomb Calorimeter:

Q: How does the BCI-3000 Bomb Calorimeter perform calibration?

A: The BCI-3000 utilizes electronic automatic calibration, ensuring accurate results with minimal manual intervention. This process enhances measurement precision and consistency by adjusting system parameters electronically before each set of tests.

Q: What safety features are integrated into the BCI-3000 Bomb Calorimeter?

A: Safety is a priority with this instrument, featuring a pressure relief valve to manage high pressures and overheat protection to prevent damage during operation. The corrosion-resistant stainless steel chamber and anti-vibration platform also contribute to operator safety.

Q: When can I use the BCI-3000 for calorific value measurement?

A: The BCI-3000 is suitable for use within operating temperatures of 10C to 40C and up to 80% relative humidity. It is designed for daily laboratory or industrial applications requiring bomb calorimetry for analyzing solid or liquid fuel samples.

Q: Where is the BCI-3000 Bomb Calorimeter typically installed and used?

A: This calorimeter is designed for bench-top mounting in laboratories or industrial testing areas. On-site installation and training are available, ensuring proper setup and seamless commissioning for your facility in India.

Q: What is the process for conducting a test with the BCI-3000?

A: Testing involves placing a 1-2g specimen into the removable combustion bomb, filling the chamber with oxygen to a maximum of 30 atm, and loading water in the jacket (up to 350 ml). The device carries out ignition and measurements automatically, then records and stores data electronically.

Q: How is data managed and retrieved from the BCI-3000?

A: Data management is streamlined with the internal memory for 100 test records, digital LCD display, and RS232 port for PC connectivity. The included software allows detailed analysis and easy data export, supporting enhanced laboratory reporting.

Q: What are the key benefits of using the BCI-3000 Bomb Calorimeter?

A: Operators benefit from fully automatic operation, high measurement accuracy (0.2%), rapid testing (less than 1 minute), strong safety features, and easy data management. Comprehensive manuals and support services provide further assurance of reliability and ease of use.
