9565-A VelociCalc Multi-Function Ventilation Meter

Get a Price/Quote

9565-A VelociCalc Multi-Function Ventilation Meter Specification

Pressure Range
0 to 5 kPa (with optional probe)

Diameter
Probe diameter: 10 mm

Sensor Type
Hot-wire anemometer for air velocity; thermistor for temperature; capacitive sensor for humidity

Resolution
Velocity: 0.01 m/s; Temperature: 0.1C; Humidity: 0.1%

Wind Speed
0 to 30 m/s

Measurement Range
Velocity: 0 to 30 m/s; Temperature: -10 to 60C

Application Media
Air (ventilation, HVAC)

Temperature Range
-10C to 60C

Humidity %
0 to 95% RH

Equipment Type
Multi-Function Ventilation Meter

Protection
Protective transport case included

Connectivity Type
USB interface for data download

Flow Rate
0 to 99,999 m/h (depending on duct size and velocity)

Capacity
Data logging up to 26,500 samples

Material
ABS plastic housing

Power Supply
4 AA-size batteries or optional AC adapter

Power Consumption
Approx. 1.2 W (using AA batteries)

Accuracy
Velocity: 3% of reading or 0.015 m/s (whichever is greater)

Display Type
LCD digital display with backlight

Range
Velocity: 0 to 30 m/s; Temperature: -10 to 60C; Humidity: 0 to 95% RH

Mounting Type
Handheld, portable use

Battery Life
Up to 40 hours (alkaline batteries)

Storage Temperature
-40 to 70C

Data Logging
Yes, up to 26,500 samples

Backlight Display
Yes

Approval/Certification
CE Marked

Software Compatibility
TSI LogDat2 or equivalent

Operating Temperature
0 to 60C

Probe Cable Length
1.8 meters

Auto Power Off
Programmable

Dimensions
Instrument: 84 mm x 178 mm x 44 mm

Upgradeability
Upgradeable firmware via USB

Weight
0.27 kg (instrument only)

Language Support
Multi-language display

Alarm Function
Audible and visual alarms for selectable measurements

About 9565-A VelociCalc Multi-Function Ventilation Meter

Applications

HVAC testing and balancing
Clean room testing
Biological safety cabinet and laboratory fume hood testing
HVAC commissioning and troubleshooting
IAQ investigations
Thermal comfort studies
Ventilation evaluations
Process air flow testing

Included items:

9565-A instrument
966 probe
Static pressure probe (1)
Tubing, 8 ft. (2.4 m)
USB cable with LogDat2 and TrakPro downloading software
Hard carrying case
Four alkaline batteries
Operation and service manuals
Calibration certificate

Features and benefits

articulated air velocity probe Model 966 measure air velocity, temperature and relative humidity
Includes differential pressure sensor
Best-in-class air velocity accuracy
Optional smart plug-in probes, including VOC, CO2, and rotating vane probes
Accommodates up to two K-alloy thermocouples
Large graphic display
Displays up to five measurements simultaneously
On-screen messages and instructions
Program for local language
Intuitive menu structure allows for ease of use and setup
Multiple data logging formats
Bluetooth communications for transferring data or remote polling
Includes TrakPro and LogDat2 downloading software with USB cable

Multi-Parameter Measurement

The VelociCalc 9565-A delivers precise readings of air velocity, temperature, and humidity-essential for HVAC technicians, safety professionals, and building engineers. Its broad measurement ranges support a wide variety of on-site monitoring needs, from optimizing ventilation systems to ensuring regulatory compliance. The backlit LCD digital display ensures information is easy to read, even in dimly lit spaces.

Advanced Data Logging and Connectivity

This meter captures and stores up to 26,500 sample points, enabling extended monitoring and post-process analysis. Access your data effortlessly via USB and compatible software such as TSI LogDat2. Programmable auto power-off and upgradable firmware keep the device efficient and up to date, while audible and visual alarms help alert users to out-of-range conditions.

Portability and User Convenience

Designed for portability, the instrument's lightweight ABS housing and protective carrying case make it suitable for field service in diverse locations. Multi-language display support, a 1.8-meter probe cable, and up to 40 hours of continuous operation on standard AA batteries provide maximum flexibility and ease of use during prolonged field assessments.

FAQ's of 9565-A VelociCalc Multi-Function Ventilation Meter:

Q: How do I use the 9565-A VelociCalc to log ventilation data during an HVAC assessment?

A: You can select the data logging function, begin sampling, and allow the meter to record readings automatically. It stores up to 26,500 samples for extended monitoring. Data can be later exported via USB with TSI LogDat2 or equivalent software for detailed analysis.

Q: What environments and conditions is the 9565-A suitable for?

A: This meter is designed for use in air monitoring applications such as ventilation, HVAC, and cleanroom environments. It operates between 0C to 60C and can be stored between -40C to 70C, accommodating a wide range of job sites and climates in India.

Q: When should I utilize the alarm functions during measurement?

A: The audible and visual alarms should be set to notify you when selected parameters exceed user-defined thresholds. This is particularly beneficial for instant identification of non-compliant or hazardous air conditions during inspections.

Q: Where can I obtain technical support or replacement accessories for this device in India?

A: Technical support and replacement accessories can be sourced through authorized distributors, manufacturers, service providers, suppliers, or traders specializing in TSI instruments across India. Ensure you contact the official distributor for genuine parts and assistance.

Q: What process should I follow to upgrade the firmware of the 9565-A VelociCalc?

A: To upgrade the firmware, connect the unit to a PC using the USB interface and follow the manufacturer's update instructions, typically provided via the official website or distributor support. This process ensures the device remains compatible with new features and software enhancements.

Q: How does the design of the 9565-A benefit users during prolonged field operations?

A: Its lightweight ABS plastic housing, ergonomic handheld design, and portable carrying case allow for comfortable extended use. Up to 40 hours of battery life and programmable auto-off features further support long field sessions without interruption.

Q: What are the advantages of using the VelociCalc 9565-A in multi-parameter air quality monitoring?

A: By combining air velocity, temperature, humidity, and optional pressure and flow rate measurements, the 9565-A streamlines comprehensive ventilation assessments, saving time and reducing equipment needs. Reliable accuracy and data logging empower users to make informed decisions for facility safety and efficiency.
